DF Series
-
LED Dance Floor,
Height Adjustable
Quick and Easy Installation
Ultra Wide Viewing Angle
Adapt to Multifarious Ground
IP65 Waterproof
| DF-2.5 | DF-2.6 | DF-2.97 | DF-3.91 | DF-4.8 | |
| Physical Pitch | 2.5mm/0.1" | 2.6mm/0.102" | 2.97mm/0.12" | 3.91mm/0.15" | 4.81mm/0.19" |
| Pixel Density | 160000px/m2 | 147456px/m2 | 112896px/m2 | 65536px/m2 | 43264px/m2 |
| Module Dimension(WxH) | 250x250mm / 9.84"x9.84" | ||||
| Panel Dimension(WxH) | 500x1000mm / 19.68"x39.37" 500x500mm / 19.68"x19.68" | ||||
| No. of Module/panel(WxH) | 2x4 2x2 | ||||
| Module Resolution | 100x100px | 96x96px | 84x84px | 64x64px | 52x52px |
| Panel Resolution | 200x400px 200x200px | 192x384px 192x192px | 168x336px 168x168px | 128x256px 128x128px | 104x208px 104x104px |
| Panel Material | Cold steel / Aluminum / Die-casting AL | ||||
| Panel Weight | 44kg/m2 | 44kg/m2 | 44kg/m2 | 44kg/m2 | 44kg/m2 |
| Gray Scale | 16bit | ||||
| Contrast Ratio | 4000:1 | ||||
| Max. Power Consumption | 800w/m2 | 800w/m2 | 800w/m2 | 800w/m2 | 800w/m2 |
| Operating Temp/Humidity | -10°C - 60°C / 10% - 60% | ||||
| Storage Temp/Humidity | -30°C - 60°C/ 10% - 60% | ||||
| Refresh Rate | 3840hz | ||||
| Application | Indoor | Indoor | Indoor | Indoor | Indoor |
| Viewing Angle(H/V) | 160°/140° | ||||
| Expected Lifetime | 100,000hrs | ||||
| Service | Front | ||||
| Certification | CCC,CE,ETL,RoHS | ||||
